pET-Dual-Avi-His-SUMO3-MCS-BirA

pET-Dual-Avi-His-SUMO3-MCS-BirA

pET-Dual-Avi-His-SUMO3-MCS-BirA is a plasmid used to express biotin-tagged proteins in E. coli. This plasmid contains two sets of T7 promoter/lac operator and ribosome binding site (RBS). One set of multiple cloning sites (MCS) is preceded by His tag, Avi tag and SUMO3 tag, and the other set is used to express biotin ligase with S tag. BirA, therefore can efficiently initiate the co-expression of the target protein and BirA under the induction of isopropylthiogalactopyranoside (IPTG). In the presence of ATP and biotin (Biotin), the intracellularly expressed biotin ligase BirA catalyzes the covalent binding of biotin to the Avi tag at the N-terminus of the target protein, so that biotin labeling can be performed while expressing the target protein. At the same time, the plasmid contains a SUMO3 tag, which can be specifically recognized and cleaved by rSENP2 protease, thereby achieving efficient separation of the corresponding tagged protein and the target protein. This plasmid is ampicillin resistant.
Get a Quote
More Details

All products have special prices for bulk purchase, please contact for more details if required.





The main information of pET-Dual-Avi-His-SUMO3-MCS-BirA plasmid is as follows:


  • Feature Nucleotide
  • Position
  • T7-1 promoter
  • 6664-2
  • Avi tag
  • 83-127
  • His tag
  • 137-154
  • SUMO3 tag
  • 161-436
  • Multiple Cloning Sites
  • 434-484
  • T7-2 promoter
  • 542-560
  • BirA
  • 631-1593
  • S tag
  • 1606-1650
  • T7 Terminator
  • 1420-1467
  • f1 origin
  • 1786-2241
  • Ampicillin
  • 2356-3216
  • ori
  • 3390-3978
  • lacI
  • 5171-6253



The map of pET-Dual-Avi-His-SUMO3-MCS-BirA plasmid (6660bp) is as follows:

pET-Dual-Avi-His-SUMO3-MCS-BirA



Restriction sites not found in pET-Dual-Avi-His-SUMO3-MCS-BirA include:


AatIIAbsIAcc65IAcvIAgeIAhlIAleI
AsiGIAsiSIAsp718IAsuIIAsuNHIBaeIBbrPI
BcuIBglIIBmtIBoxIBplIBpu14IBshTI
BsiWIBsp68IBsp119IBspOIBspT104IBstBIBstPAI
BstSNIBtuMICfr9ICfr42ICpoICsiICspI
Csp45ICspAICspCIEco32IEco72IEco105IEcoRV
EcoT22IFalIFseIFspAII-CeuII-PpoII-SceI
KflIKpnIKspIMabIMauBIMfeIMph1103I
MreIMssIMunINheINruINsiINspV
OliIPfl23IIPI-PspIPI-SceIPinAIPmaCIPmeI
PmlIPshAIPspCIPspLIPsrIRgaIRigI
RruIRsrIIRsr2ISacIISanDISexAISfaAI
SfiISfr303ISfuISgfISgrBISgrDISmaI
SmiISnaBISpeISrfISstIISwaITspMI
XmaIXmaCIZraIZsp2I


The single enzyme cutting sites in pET-Dual-Avi-His-SUMO3-MCS-BirA include:


AflIIA`CRYG,T491NotIGC`GGCC,GC478
AhdIGACNN,N`NNGTC2429PacITTA,AT`TAA1669
AvrIIC`CTAG,G1673PaeR7IC`TCGA,G1594
BamHIG`GATC,C434PciIA`CATG,T4034
BbvCICC`TCA,GC1111PflFIGACN`N,NGTC4292
BmgBICAC|GTC412PpuMIRG`GWC,CY5029
BspQIGCTCTTCN`NNN,4151PsiIA`CATG,T2144
BsrGIT`GTAC,A518PspXIVC`TCGA,GB1594
BstAPIGCAN,NNN`NTGC6222PvuICG,AT`CG2799
BstEIIG`GTNAC,C5716SacIG,AGCT`C450
BstZ17IGTA|TAC4267SalIG`TCGA,C465
Bsu36ICC`TNA,GG1576SapIGCTCTTCN`NNN,4151
DraIIICAC,NNN`GTG2019ScaIAGT|ACT2909
Eco53kIGAG|CTC448SgrAICR`CCGG,YG6579
EcoRIG`AATT,C440SphIG,CATG`C6431
FspITGC|GCA2651SspIAAT|ATT2224
HindIIIA`AGCT,T471StuIAGG|CCT293
HpaIGTT|AAC5396Tth111IGACN`N,NGTC4292
MluIA`CGCG,T5898XbaIT`CTAG,A30
NcoIC`CATG,G69XhoIC`TCGA,G1594
NdeICA`TA,TG626



The recommended sequencing primer sequences for pET-Dual-Avi-His-SUMO3-MCS-BirA plasmid are as follows:
T7-R (542-561): 5'-CCCTATAGTGAGTCGTATTA-3'


Storage Conditions

Store at -20 °C.


Precautions

  • No commercial use of this plasmid is permitted without written permission from SBS Genetech. Nor shall it be transferred to any individual or institution outside the purchaser’s laboratory.
  • This product is intended solely for scientific‑research use by professionals. It shall not be adopted for clinical diagnosis or therapy, food‑related or pharmaceutical applications, nor kept in residential premises.
  • For your safety and health, wear a lab coat and disposable gloves during operation.





Only for research and not intended for treatment of humans or animals
